| Item | Parameters:110kW/233kWh |
|---|---|
| Cell | LFP280Ah |
| System Battery Configuration | 5 Packs*1P52S |
| Nominal Voltage（V） | 832 |
| Operating Voltage (V） | 728~936 |
| Rated Energy（kWh） | 232.96 |
| Rated Power(kW） | 110 |
| Weight（kg） | ≈2700 |
| Dimension (mm) | 935*1350*2480mm |
| Storage Temperature（℃） | -40~+60 |
| System Conversion Efficiency | ≥86% |
| Rated Power | 100kVA |
| Wiring Method | Three-phase Four-wire |
| ACOverloadCapacity | 110kVA |
| Grid Voltage Range | 400V(-20%~+15%) |
| Grid Frequency Range | 50/60(-2.5-2.5) |
| THD | ≤3% |
| Power Factor | 0.99/-1~1 |
| Maximum Conversion Efficiency | 98.5% |
