| Item | Parameters |
|---|---|
| Model | Home Vp48100 |
| Cell | 100Ah |
| Energy | 5120Wh |
| Rated Voltage | 51.2V |
| Max Charging Voltage | 56.8V |
| Max Charge/Discharge Current | 100A |
| Discharge Cut-off Voltage | 44.8V |
| Communication Solution | RS485,CAN,USB |
| Cycle Life | 6000 cycles(25℃±2℃，0.2C/0.2C,80%DOD) |
| Charging Temperature | 0-55℃ |
| Discharging Temperature | -20-55℃ |
| Dimensions | 480*600*150mm |
| Weight | 52kg |
| Installation Method | Wall-mounted/floor-mounted |
| Certification | UN38.3,CE,MSDS |
| Item | Parameters |
|---|---|
| Model | Home Vp48100 |
| Cell | 200Ah |
| Energy | 10240Wh |
| Rated Voltage | 51.2V |
| Max Charging Voltage | 56.8V |
| Max Charge/Discharge Current | 200A |
| Discharge Cut-off Voltage | 44.8V |
| Communication Solution | RS485,CAN,USB |
| Cycle Life | 6000 cycles(25℃±2℃，0.2C/0.2C,80%DOD) |
| Charging Temperature | 0-55℃ |
| Discharging Temperature | -20-55℃ |
| Dimensions | 480*650*240mm |
| Weight | 85kg |
| Installation Method | Wall-mounted/floor-mounted |
| Certification | UN38.3,CE,MSDS |
