| Item | Parameters | Remarks |
|---|---|---|
| Cell | LFP314Ah | 0.5P |
| System Battery Configuration | 12 Clusters*4 Packs*1P104S | |
| Nominal Voltage (V) | 1331.2 | |
| Operating Voltage (V) | 1164.8-1497.6 | Cell:2.8-3.6 |
| Rated Power(MW) | 2.5 | 0.5P |
| Rated Energy(MWh) | 5.016 | |
| Operating Temperature (℃) | Charge:0~55,Discharge:-20~55 | |
| Storage Temperature(℃) | -40-60 | |
| Operating Relative Humidity | 0-95%(No Condensation) | |
| Altitude | ≤2000 (Use Derating 2000) | |
| Cooling Method | Liquid Cooling | |
| Fire Protection | Pack and Container Fire Protection (Perfluorohexane.Water) | |
| Protection Rating | Container:IP55;Pack IP67 | |
| Anti-corrosion Grade | C5 (Optional) | |
| Dimension(mm) | 6058*2438*2896 | |
| Weight (t) | ≈43 |
