| Category |
Parameter |
Specification |
| AC Input |
Input Mode |
Single-phase two-wire (L/N) |
| Output Voltage Waveform |
Pure sine wave |
| Rated Voltage |
230Vac |
| Voltage Range |
90–280Vac ±5V |
| Frequency Range |
45–65Hz |
| Power Factor |
>0.95 |
| AC Charging Power |
500W |
| PV Input |
Nominal PV Voltage |
30V |
| Voltage Range |
10–55Vdc |
| Maximum Current |
10A |
| Maximum Power (MPPT) |
300W |
| AC Output |
Output Mode |
Single-phase two-wire |
| Rated Voltage |
230Vac ±5V |
| Rated Frequency |
50Hz ±0.5% |
| Power Factor |
≥0.99 |
| Full Load Power |
500W |
| UPS Switching Time |
≤20ms |
| Maximum Inverter Efficiency |
88% |
| DC Output |
Output Voltage |
5V |
| Output Current |
1A |
| Maximum Output Power |
5W |
| Battery |
Rated Voltage |
3.2V |
| Voltage Range |
2.9–3.65V |
| Capacity |
314Ah |
| Rated Energy |
1004.8Wh |
| Maximum Charging Current |
140A |
| Maximum Charging Power |
500W |
| Protection Function |
Undervoltage/Overvoltage Protection |
Yes |
| Short Circuit Protection |
Yes |
| Over-temperature Protection |
Yes |
| Display Function |
LED Indicator Light |
4 SOC power indicators, 1 working status indicator |
| LED Power Indicator |
25/50/75/100% |
| Environment |
Operating Temperature
|
-10℃ ~ 50℃
|
Storage Temperature
|
-15℃ ~ 60℃
|
Humidity
|
20%–95% RH（without condensation）
|
Altitude
|
≤3000m
|
Noise
|
<40dB
|
| General Data |
Product Dimensions (mm)
|
356×210×156mm
|
Packaging Dimensions (mm)
|
412×262×212mm
|
Net Weight (kg)
|
11kg
|
Gross Weight (kg)
|
12kg
|
