LFP Chemistry Cell Design
Liquid Cooling Temperature Control
Multi-Level Structure Protection
Standard Container Dimensions
ModularInternal Configuration
EfficientEnergyCapacityUpgrade
Pre-Commissioning Integration
Intelligent Monitoring
Stable Power Multi-Scenario Adaptation
| Item | Parameters | Notes |
|---|---|---|
| Configuration | 416S8P | 8 strings |
| Rated Capacity | 8*565Ah | 32 Blocks |
| Nominal Voltage | 1331.2V | |
| Voltage Range | 1040~1497.6V | |
| Rated Energy | 6017kWh | |
| Continue Power | ±1504kW | 0.25P |
| Cooling Method | liquid | |
| Dimensions | 6400×2438×2896mm | L×W×H |
| Weight | 50000kg | |
| IP grade | IP55 |
