| Item | Parameters:200kW/418kWh |
|---|---|
| Cell | LFP314Ah |
| System Battery Configuration | 8 Packs*1P52S |
| Nominal Voltage（V） | 1331.2 |
| Operating Voltage (V） | 1164.8~1497.6 |
| Rated Energy（kWh） | 417.997 |
| Rated Power(kW） | 200 |
| Weight（kg） | ≈3800 |
| Dimension (mm) | 1430*1405*2650 |
| Storage Temperature（℃） | -40~+60 |
| System Conversion Efficiency | ≥86% |
| Rated Power | 215kVA |
| Wiring Method | Three-phase Four-wire |
| ACOverloadCapacity | 237kVA |
| Grid Voltage Range | 690(-15%~10%)V |
| Grid Frequency Range | 50/60(-5~5) |
| THD | ≤3% |
| Power Factor | 0.99/-1~1 |
| Maximum Conversion Efficiency | 99% |
