| Item | Parameters:125kW/261kWh |
|---|---|
| Cell | LFP314Ah |
| System Battery Configuration | 5 Packs*1P52S |
| Nominal Voltage（V） | 832 |
| Operating Voltage (V） | 728~936 |
| Rated Energy（kWh） | 261.24 |
| Rated Power(kW） | 125 |
| Weight（kg） | ≈2730 |
| Dimension (mm) | 1000*1350*2350mm |
| Storage Temperature（℃） | -40~+60 |
| System Conversion Efficiency | ≥86% |
| Rated Power | 125kVA |
| Wiring Method | Three-phase Four-wire |
| ACOverloadCapacity | 137.5kVA |
| Grid Voltage Range | 380/400(-15%~15%) |
| Grid Frequency Range | 50/60（-2.5~2.5) |
| THD | ≤3% |
| Power Factor | 0.99/-1~1 |
| Maximum Conversion Efficiency | 99% |
