Lightweight & Optimized Cooling Path
Effective Temperature Consistency
5-15% Efficiency Boost at Low Load
Longer Cycle Life via Stable Cooling
| Rated Capacity | 100Ah | 150Ah | 230Ah | 306Ah | 324Ah | 340Ah |
|---|---|---|---|---|---|---|
| Type | LFP | LFP | LFP | LFP | LFP | LFP |
| Volume Energy Density | 329wh/L | 189wh/L | 380wh/L | 392wh/L | 410wh/L | 410wh/L |
| Continuous Charge Rate | 1C | 1C | 1C | 1C | 1C | 1C |
| Continuous Discharge Rate | 1C | 1C | 2C | 1C | 1C | 1C |
| RT cycle | ≥4000cycles | ≥3000 cycles | ≥6000 cycles | ≥3000 cycles | ≥3500cycles | ≥8000cycles |
| Item | Model | Cell | Rated Energy | Rated Voltage | Voltage Range | Max. Cont. Charging Power |
Peak Charging Power |
Max. Cont. Discharging Power |
Peak Discharging Power |
RT cycle |
|---|---|---|---|---|---|---|---|---|---|---|
| Parameters | G/24-24 | 100Ah | 24.96Kwh | 249.6V | 195~284.7V | 24.96Kw | 49.92KW | 24.96Kw | 74.88Kw | ≥4000cycles |
| Parameters | G/28-28 | 150Ah | 28.8Kwh | 192V | 150~219V | 28.8Kw | 57.6Kw | 28.8Kw | 86.4Kw | ≥3000cycles |
| Parameters | G/28-31 | 230Ah | 28.7Kwh | 124.8V | 97.5~142.35V | 28.7Kw | 57.41Kw | 57.41Kw | 57.41Kw | ≥6000cycles |
| Parameters | G/29-24 | 306Ah | 306Ah | 96V | 75~109.5V | 24Kw | 48Kw | 24Kw | 48Kw | ≥3000cycles |
| Parameters | G/31-24 | 324Ah | 31.1Kwh | 96V | 75~109.5V | 24Kw | 48Kw | 24Kw | 48Kw | ≥3500cycles |
