Lightweight & Optimized Cooling Path
Effective Temperature Consistency
5-15% Efficiency Boost at Low Load
Longer Cycle Life via Stable Cooling
| Rated Capacity | 100Ah | 150Ah | 230Ah | 306Ah | 324Ah |
|---|---|---|---|---|---|
| Type | LFP | LFP | LFP | LFP | LFP |
| Volume Energy Density | 329wh/L | 189wh/L | 380wh/L | 392wh/L | 410wh/L |
| Continuous Charge Rate | 1C | 1C | 1C | 1C | 1C |
| Continuous Discharge Rate | 1C | 1C | 2C | 1C | 1C |
| RT cycle | ≥4000cycles | ≥3000 cycles | ≥6000 cycles | ≥3000 cycles | ≥3500cycles |
| Item | Model | Cell | Rated Energy | Rated Voltage | Voltage Range | Max. Cont. Charging Power |
Peak Charging Power |
Max. Cont. Discharging Power |
Peak Discharging Power |
RT cycle |
|---|---|---|---|---|---|---|---|---|---|---|
| Parameters | C lite/29-29 | 100Ah | 29.76Kwh | 297.6V | 232.5~339.45V | 29.76Kw | 59.52Kw | 29.76Kw | 89.28Kw | ≥4000cycles |
| Parameters | C lite/33-33 | 150Ah | 33.12Kwh | 220.8V | 172.5~251.85V | 33.12Kw | 66.24Kw | 33.12KW | 99.36Kw | ≥3000 cycles |
| Parameters | C lite/35-38 | 230Ah | 35.33Kwh | 153.6V | 120~175.2VW | 35.33Kw | 70.66Kw | 38.4Kw | 76.8Kw | ≥6000 cycles |
| Parameters | C lite/35-28 | 306Ah | 35.25Kwh | 115.2W | 90~131.4V | 28.8Kw | 57.6Kw | 28.8Kw | 57.6Kw | ≥3000 cycles |
| Parameters | C lite/38-28 | 340Ah | 38.43Kwh | 113.04V | 90131.4W | 28.26Kw | 56.52Kw | 28.26Kw | 56.52Kw | ≥3500cycles |
