| Item |
Parameters |
Parameters |
| Cell |
LFP314Ah |
0.5P |
| System Battery Configuration |
12 Clusters* 4 Packs*1P104S |
|
| Nominal Voltage (V) |
1331.2 |
|
| Operating Voltage(V) |
1164.8~1497.6 |
Cell:2.8~3.6 |
| Rated Power（MW） |
2.5 |
0.5P |
| Rated Energy (kWh) |
5.016 |
|
| Operating Temperature(℃) |
Charge:0~55,Discharge:-20~55 |
|
| Storage Temperature(℃) |
-40~60 |
|
| Operating Relative Humidity |
0-95%(No Condensation) |
|
| Altitude |
≤2000(Use Derating>2000) |
|
| Cooling Method |
Liquid Cooling |
|
| Fire Protection |
Pack and Container Fire Protection (Perfluorohexane、Water) |
|
| Protection Rating |
Container: IP55; Pack:IP67 |
|
| Anti-corrosion Grade |
C5(Optional) |
|
| Dimension (mm) |
6058*2438*2896 |
|
| Weight ( kg) |
≈43 |
|
