| Item | Parameters: 110kW/233kWh | Parameters: 125kW/261kWh |
| Cell | LFP280Ah | LFP314Ah |
| System Battery Configuration | 5 Packs*1P52S | 5 Packs*1P52S |
| Nominal Voltage (V) | 832 | 832 |
| Operating Voltage(V) | 728~936 | 728~936 |
| Rated Energy (kWh) | 232.96 | 261.24 |
| Rated Power（MW） | 110 | 125 |
| Weight ( kg) | ≈2700 | ≈2730 |
| Dimension (mm) | 935*1350*2480mm | 1000*1350*2350mm |
| Storage Temperature(℃) | -40~+60 | -40~+60 |
| System Conversion Efficiency | ≥86% | ≥86% |
| AC Side | ||
| Rated Power | 100kVA | 125kVA |
| Wiring Method | Three-phase Four-wire | Three-phase Four-wire |
| AC Overload Capacity | 110kVA | 137.5kVA |
| Grid Voltage Range | 400V(-20%~+15%) | 380/400(-15%~15%) |
| Grid Frequency Range | 50/60(-2.5~2.5) | 50/60(-2.5~2.5) |
| THD | ≤3% | ≤3% |
| Power Factor | 0.99/-1~1 | 0.99/-1~1 |
| Maximum Conversion Efficiency | 0.985 | 0.99 |
| Item | Parameters: 186kW/372kWh | Parameters: 200kW/418kWh |
| Cell | LFP280Ah | LFP314Ah |
| System Battery Configuration | 8 Packs*1P52S | 8 Packs*1P52S |
| Nominal Voltage (V) | 1331.2 | 1331.2 |
| Operating Voltage(V) | 1164.8~1497.6 | 1164.8~1497.6 |
| Rated Energy (kWh) | 372.736 | 417.997 |
| Rated Power（MW） | 186 | 200 |
| Weight ( kg) | ≈3800 | ≈3842 |
| Dimension (mm) | 1430*1405*2650 | 1430*1405*2650 |
| Storage Temperature(℃) | -40~+60 | -40~+60 |
| System Conversion Efficiency | ≥86% | ≥86% |
| AC Side | ||
| Rated Power | 215kVA | 215kVA |
| Wiring Method | Three-phase Three-wire | Three-phase Three-wire |
| AC Overload Capacity | 237kVA | 237kVA |
| Grid Voltage Range | 690(-15%~10%)V | 690(-15%~10%)V |
| Grid Frequency Range | 50/60(-5~5) | 50/60(-5~5) |
| THD | ≤3% | ≤3% |
| Power Factor | 0.99/-1~1 | 0.99/-1~1 |
| Maximum Conversion Efficiency | 99% | 99% |
